Tag is not equal to Fuel System

• 90° Compact Elbow Design – Optimized right-angle configuration improves hose routing in tight engine bays, reducing line stress and sharp bends.
• Dual Sealing System – 37° AN flare provides secure metal-to-metal sealing, while the 60° tapered NPT thread ensures tight pipe-side engagement.
• Multiple AN to NPT Combinations – Wide size range supports custom fuel, oil, coolant, and power steering system builds.
• 6061-T6 Aluminum Construction – Lightweight yet high-strength material with corrosion-resistant black anodized finish.
• Performance-Ready Fitment – Designed for high-pressure automotive fluid systems and easy wrench installation.

• [Universal]It can be applied to most cars, making sure there's enough room for Installation.
• [Size] Hose length: 31.5in / 0.8m,hose ID:3/8",hose OD:2/3".The thread of the inlet and outlet is M16*1.5.Capacity:300ML.
• [Baffled] The baffle is disassembled in a rotary manner, adding an appropriate amount of steel balls can increase the surface area of steam condensation and more effectively catch oil.
• [Note] When the temperature outside reaches the freezing point or below, the crank vent system will generate a much greater amount of moisture which can present a risk of freezing. Please clean your oil catch can on a weekly or install the original PCV hose.
• Oil Catch Can with or without Breather Filter: Install the oil catch can with breather filter for pre-PCV cars as a vent system or without breather filter in line between PCV hoses as a seal can.

• Size: M14*1.5 male-to-barb fitting thread; compatible with 3/8" ID pipe; 1L storage volume.
• Fitment: Universal coolant reservoir tank, suitable for most vehicles (measure installation space before purchase).
• Note: Features tight-closed cap, fully TIG-welded construction, and O-ring gasket on threads for leak prevention; Teflon tape is recommended during installation to enhance airtightness.
• Function: When radiator coolant pressure exceeds cap setting, coolant flows into the tank via overflow tube; bottom port for radiator overflow, top port for tank overflow.
• Warranty: 1-year warranty provided by EVIL ENERGY.

• Precision Fitment – Available in AN3, AN4, AN6, AN8, AN10, AN12 with UNF thread sizing for accurate hose-to-fuel system connections.
• High Pressure & Temperature Rated – Supports up to 1500 PSI working pressure and -40°F to 248°F temperature range for reliable performance.
• Optimized for Tight Spaces – 45° angled design and 360° swivel head simplify routing in compact or angled fuel line installations.
• Leak-Free Seal – 37° flare ensures a secure, anti-leak connection without additional sealants.
• Durable Construction – Made from 6061-T6 aluminum alloy with a black anodized coating for corrosion resistance and long service life.

Built for flexibility and reliability, the EVIL ENERGY Push Lock Fuel Hose SAE 30R7 is a go-to solution for fuel system routing. Made from durable NBR rubber reinforced with braided polyester, it supports up to 300 PSI and resists wear, heat, and fuel additives. Ideal for custom setups in classic cars, LS swaps, oil coolers, and more, this hose is compatible with gasoline, diesel, biodiesel, and oil.

EVILENERGY Fuel Line Kits: Power, Performance, and Reliability!

• Upgrade with EVILENERGY's fuel line kits. Durable Nylon and CPE rubber hoses, reinforced with 304 steel wire, ensure strength. Available in 4AN, 6AN, 8AN, 10ANand 12AN sizes, each kit includes a 20FT line and fittings for easy install. Wide temp range (-22°F to 248°F) and high pressure make them reliable. Measure before purchase. Enhance your ride today!

• Bracket Kit Included: 1 x Oil Cooler Mounting Bracket , 2 x Accessory Bracket, 8 x Screw , 8 x Nut，1 x Oil Cooler,1 x CPE 6AN Fuel Line Kit.
• Oil Cooler Size:

10 Row:13.38"× 6.5"× 1.97"inch. Oil capacity: 0.55L.
16 Row:12.91"× 5.71"× 1.97"inch. Oil capacity: 0.39L.
19Row:12.91" × 6.67"× 1.97"inch. Oil capacity: 0.45L.
30 Row:12.91"× 10.04"×1.97"inch. Oil capacity: 0.74L.

• Application: Oil cooler is suitable for most vehicles. Please ensure enough space for installation.
• Fuction: The stacked plate oil cooler has high cooling efficiency and improves the lubrication of engine oil. Used to cool engines, transmissions, and rear differentials.
• Material: aluminum alloy made,lightweight cooler mounting.

[Bundle with]
Fuel Pump(Optional):
- 300LPH External Fuel Pump Fitting Kit
- 255LPH Intank
- 110LPH Intank
Fuel Filter (Optional): 10 Micron/30 Micron/40 Micron/100 Micron
Bracket: 50MM/60MM

Note：Please pay attention to the dimensions and choose the product that best fits your needs.

Kit Components: Braided nylon fuel hose + aluminum alloy swivel fittings

Hose Specs: 4/6/8/10/12AN sizes; 10/12/16/20FT lengths; Black/Black&Red colors

Hose Structure: 3-layer (CPE inner + 304 stainless steel mesh + nylon braid)

Fitting Quantity & Types:
- 6PCS: 2×Straight + 2×45° + 2×90° swivel ends;
- 10PCS: 4×Straight + 2×45° + 2×90° + 2×80° swivel ends;
- 12PCS: 4×Straight + 2×45° + 2×90° + 2×180° swivel ends + 2×(AN-AN or AN-NPT) fittings
Pressure Ratings: Max working pressure 500-750PSI; bursting pressure 1500-2250PSI

Applications: Suitable for transmission fluid, oil, race gas, fuel, diesel, hydraulic fluid, vacuum

Warranty: 6 months

High-performance 12V radiator cooling fans available in 5 sizes (8-16 inches), featuring powerful 80W motors and efficient blade designs. Each fan kit includes a thermostat relay switch (175-185 Degree) and complete mounting hardware for universal installation.

• Conductive PTFE Core – Built with a carbon-impregnated inner layer to safely discharge static buildup. Critical protection when running E85, methanol, or high-flow EFI systems.
• True 6/8/10AN Size – High-volume fuel flow for 800–1000+ horsepower applications.
• Extreme Pressure & Heat Resistance – Rated to 1250 PSI working pressure and up to 446°F; ideal for EFI, turbo, supercharged, or race fuel setups.
• Fully E85-Compatible – Resists ethanol corrosion, fuel permeation, and temperature damage over time.
• Durable Nylon Braided Outer Shell – Offers abrasion resistance and maintains flexibility while protecting the PTFE core.

Upgrade your vehicle’s fuel system with the EVIL ENERGY SAE 30R9 Fuel Injection Hose – engineered for high-performance applications like EFI conversions and LS swaps. Built with an FKM inner core, reinforced with aramid fiber, and wrapped in ECO rubber, this hose delivers superior resistance to ethanol-based fuels, high pressure (300 PSI), and extreme temperatures. Available in 1/4", 5/16", and 3/8" ID sizes and multiple lengths to suit custom installations.
