AN to AN Fittings

Fitment

• Fit For 66-79 Ford F100 F150 F250 F350 Bronco Truck V8

Core Engineering

• 3-row 44mm core with staggered fin design maximizes turbulent airflow for balanced thermal dissipation.
• Core dimensions: 25.91' (L) × 18.9' (H) × 1.73' (T)
• Brazed aluminum construction eliminates epoxy joints, enhancing long-term structural integrity.

Fluid Dynamics Optimization

• 6.61L coolant capacity accommodates extended off-road cycles.
• 1.97’ outlet and 1.77‘ inlet hydraulic resistance
• M12 × 1.5 threaded drain plug simplifies maintenance.

Vehicle Fitment

• fit for 1988-2000 GM GMT400 Platform: C/K Trucks, Tahoe/Yukon, Suburban & Escalade V8 Engines (5.7L-7.4L)

Cooling Feature

• The full aluminum radiator is lightweight and high heat transferring aluminum features a tube and fin design,that dramatically increases surface area that enables the heat to dissipate more efficiently. It provides 30% more cooling capacity than a standard radiator.
• 4-row 60mm core with staggered fin design maximizes turbulent airflow for balanced thermal dissipation.
• Core dimensions: 16.85' (L) × 33.98' (H) × 2.36' (T)
• Brazed aluminum construction eliminates epoxy joints, enhancing long-term structural integrity.

Direct Replacement

• Carefully crafted to exceptional OE standards for precise fit. CNC turret punch machine ensure the accuracy of radiator size. No Drilling or Modifications Needed for Installation.

Fluid Dynamics Optimization

• 7.13L coolant capacity accommodates extended off-road cycles.
• 1.57’ outlet and 1.26‘ inlet hydraulic resistance
• M12 × 1.5 threaded drain plug simplifies maintenance.
