Product Details

Brand	EVIL ENERGY
Material	Nylon, Synthetic Rubber
Color	Black
Size	4AN/6AN/8AN/10AN/12AN
Length	5FT/10FT/12FT/16FT/20FT/25FT
Hose ID	4AN ID: 7/32" (0.22inch) 6AN ID: 0.34" 8AN ID: 0.43" 10AN ID: 0.55" 12AN ID: 0.69 inch 20AN ID:1.125 inch
Hose OD	4AN OD: 0.43inch 6AN OD: 0.54inch 8AN OD: 0.64inch 10AN OD: 0.78inch 12AN OD: 0.96 inch 20AN OD: 1.45 inch
Maximum Working Pressure	4/6/8/10AN: 500psi; 12AN: 350psi
Bursting Pressure	4/6/8/10AN: 2000psi; 12AN: 1400psi
Temperature Range	-40℉ to 257℉
Min Bending Radius	4AN: 50.8mm 6AN: 63.5mm 8AN: 88.9mm 10AN: 101.6mm 12AN: 114.3mm

About this item

[Material]: This fuel hose features an inner layer of CPE rubber, reinforced with a 304 steel wire layer and a durable nylon outer braid.
[Compatibility]: Perfect for a variety of fluids including transmission fluid, oil, race gas, vacuum, hydraulic fluid, diesel, and fuel.
[Versatile Usage]: Ideal for applications like transmission oil cooler lines, fuel return lines, fuel supply lines, and coolant fluid hoses.
[Warranty]: EVIL ENERGY provides a 6-month warranty. For any questions, contact us at support@ievilenergy.com.

EVIL ENERGY 4/6/8/10/12AN CPE Nylon Braided Fuel Hose Line 5-25FT

EVIL ENERGY 4/6/8/10/12AN CPE Nylon Braided Fuel Hose Line

EVIL ENERGY CPE Nylon Braided Fuel Hose Line

Why Choose Evil Energy?

Elevate your vehicle's performance with our top-tier fuel system components, including fuel lines, fittings, adapters, filters, fuel pumps, pressure regulators, and catch cans.

We prioritize quality control, ensuring each component meets rigorous standards for perfect fitment and durability, effectively addressing common fuel system challenges faced by car enthusiasts.

Enhanced Performance: Our products boost efficiency and power for your modified engine.
Professional Grade: Ideal for serious modifiers seeking reliable and high-performance upgrades.
Fast Shipping: Orders are processed within 1-2 business days for quick delivery.
Easy Returns: Enjoy a hassle-free 90-day return policy with free return shipping (Requires no use or installation, packaging intact). 90-180 days will be charged a 15% operating fee.
Warranty: EVIL ENERGY provides 1-year warranty on this kit. For questions, reach out to us via email.

For additional information, please contact us at support@ievilenergy.com.

Q&A

Q1: What fluids can this fuel hose handle?
A1: The EVIL ENERGY CPE Nylon Braided Fuel Hose Line is designed to handle a wide range of fluids, including transmission fluid, oil, race gas, vacuum, hydraulic fluid, diesel, and fuel.

Q2: What is the maximum working pressure for the different sizes?
A2: The maximum working pressure is 500 psi for sizes 4AN, 6AN, 8AN, and 10AN, and 350 psi for size 12AN.

Q4: Can this hose be used for turbo applications?
A4: Absolutely! This hose is suitable for various applications, including turbo cooler lines and oil feed lines.

INSTALLATION GUIDE

Moderate Estimated Time: 0.5-1 hour

Tools Required

AN wrench set
Bench vise
Hose cutter or fine-tooth hacksaw
Deburring tool
Marker
Assembly lubricant
Safety glasses
Fuel-resistant gloves

Pre-Installation Checklist

Confirm whether the supplied hose is CPE, PTFE, or antistatic PTFE and use the matching assembly method.
Plan the routing path away from exhaust heat, moving parts, sharp edges, and abrasion points.
Confirm the correct hose ends and AN fittings are available.
Wear safety glasses and fuel-resistant gloves and work away from ignition sources.

Installation Steps

Measure the hose along the intended routing path and allow enough length for bends without kinks or tension.
Wrap the cutting area with tape, make a square cut, then deburr and clean the hose end.
For CPE hose, secure the socket in a vise, thread the hose into it until snug, leave a 1-1.5 mm gap, and mark the hose position.
For PTFE hose, slide on the socket, flare back the outer braid, seat the ferrule fully on the PTFE liner with no gap, and push the assembly onto the nipple.
Apply assembly lubricant to the fitting threads, hold the socket securely, and tighten the fitting body until fully seated.
Clean and pressure-test the completed hose assembly before installing it.
Install the hose according to the system flow diagram and secure it away from heat, sharp edges, and moving parts.

Post-Installation Verification

Verify all hose ends are fully seated and fittings are secure without overtightening.
Confirm no hose is kinked, twisted, under tension, or exposed to abrasion or excessive heat.
Pressure-test the assembly and inspect every connection for leaks before starting the engine.
Reinspect after the road test and after 50-100 km.

Troubleshooting

Fuel leak: turn the ignition OFF immediately and replace damaged hose or fittings before operation.
Restricted flow or low pressure: inspect for kinks, incorrect routing, debris, or an incomplete hose-end assembly.
Air entering the system or fluctuating pressure: check all hose ends and fittings for loose connections or leaks.

Maintenance

Inspect hose routing, abrasion protection, and fittings periodically.
Replace any hose that is damaged, leaking, kinked, or heat-affected before operating the vehicle.
